TP-Link TL-SF1008P User Manual

9
Appendix A: Specifications
General
Standard IEEE802.3,IEEE802.3u,IEEE802.3x,IEEE802.3af
Protocol CSMA/CD
Ethernet: 10Mbps (Half Duplex)
20Mbps (Full Duplex)
Data Transfer
Rate
Fast Ethernet: 100Mbps (Half Duplex)
200Mbps (Full Duplex)
10Base-T:
UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Network
Media(Cable)
100Base-TX:
UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Number of
Ports
8 10/100Mbps Auto-Negotiation RJ45 ports with
PoE enabled (port-1 ~ port-4)
PoE Power on
RJ45
Power+: pin 3 & pin 6
Power -: pin 1 & pin 2
LEDs Power, Link/Act, 100Mbps, PoE Status, PoE MAX
Transfer
Method
Store-and-Forward
MAC Address
Learning
Automatically learning, automatically aging
10Base-T: 14880pps/Port
Frame Filter
Rate
100Base-Tx: 148800pps/Port
10Base-T: 14880pps/Port
Frame
Forward Rate
100Base-Tx: 148800pps/Port

TP-Link TL-SF1008P Specifications

General

Heat dissipation	248.93 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
User guide	Yes
Package type	Box
Package depth	280 mm
Package width	223 mm
Package height	68 mm
Package weight	970 g
10G support	No
Networking standards	IEEE 802.3, IEEE 802.3af, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Copper ethernet cabling technology	10GBASE-T, 100BASE-TX
Forwarding rate	1.1904 Mpps
MAC address table	2000 entries
Total Power over Ethernet (PoE) budget	57 W
Power over Ethernet plus (PoE+) ports quantity	8
Switch type	Unmanaged
Product color	Black
Housing material	Metal
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Fast Ethernet (10/100)
Power source	DC/PoE
Input current	1.31 A
AC input voltage	220 V
DC input voltage	53.5 V
AC input frequency	50 Hz
Power consumption (max)	66 W
Harmonized System (HS) code	85176990
IPv4 & IPv6 features	IPv6 portal
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	98 mm
Width	171 mm
Height	27 mm
