TP-Link TL-SG1008P User Manual

5
2) Then, the 1000Mbps and Link/Act LED indicators will flash
momentarily for one second, which represents a resetting of
the system.
Note
If the LED indicators don’t respond as described above, please
check the power supply and its connection.
Chapter 3. Identifying External Components
This Chapter describes the front panel, rear panel and LED indi-
cators of the Switch.
3.1 Front Panel
Figure 3-1 TL-SG1008P Switch Front Panel
The Switch’s LEDs are located on the front panel.
Name Status Indication
On
(green)
The Switch is powered on.
Power
Off The Switch is powered off.

TP-Link TL-SG1008P Specifications

General

Switch type	Managed
Quality of Service (QoS) support	No
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Flow control support	Yes
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Jumbo frames	16000
Forwarding rate	11.904 Mpps
MAC address table	4000 entries
Power source	DC/PoE
Input current	1.31 A
AC input voltage	100 - 240 V
DC input voltage	53.5 V
AC input frequency	50/60 Hz
Power consumption (max)	75 W
Number of power supply units	1
Product color	Gray
Housing material	Metal
Heat dissipation	225.75 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Total Power over Ethernet (PoE) budget	64 W
Power over Ethernet (PoE) ports quantity	4
Package type	Box
Package depth	280 mm
Package width	223 mm
Package height	68 mm
Package weight	900 g
Cables included	AC
Maximum cable length	100 m
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	98 mm
Width	171 mm
Height	27 mm
