TP-Link TL-SG1008P User Manual

7
Note
If all PoE PDs power consumption is >= 53W, a priority* will be
arranged among the PoE ports like port-1 = port-2 = port-3 >
port-4, then the system will cut off the power of the
lowest-priority port.
*Priority: This function will help protect the system when the
system power is overloaded. For example, Port 1, 2
and 4 is using 15.4W (maximum power for per port is
15.4W); the system power is 46.2W in total. If there is
an additional PD inserted to Port 3 with 10W, and
then the system will cut off the power of Port 4
because of the overloaded power, this means Port 1, 2
will use 15.4W, and Port3 will use 10W, no power
will be supplied to Port 4.
3.2 Rear Panel
Figure 3-2 TL-SG1008P Switch Rear Panel
The following parts are located on the rear panel:
¾ Power (48V): 48V indicates the input voltage of the power
adapter provided with this TL-SG1008P Switch. The Power
socket is where you will connect the power adapter.

TP-Link TL-SG1008P Specifications

General

Switch type	Managed
Quality of Service (QoS) support	No
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Flow control support	Yes
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Jumbo frames	16000
Forwarding rate	11.904 Mpps
MAC address table	4000 entries
Power source	DC/PoE
Input current	1.31 A
AC input voltage	100 - 240 V
DC input voltage	53.5 V
AC input frequency	50/60 Hz
Power consumption (max)	75 W
Number of power supply units	1
Product color	Gray
Housing material	Metal
Heat dissipation	225.75 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Total Power over Ethernet (PoE) budget	64 W
Power over Ethernet (PoE) ports quantity	4
Package type	Box
Package depth	280 mm
Package width	223 mm
Package height	68 mm
Package weight	900 g
Cables included	AC
Maximum cable length	100 m
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	98 mm
Width	171 mm
Height	27 mm
