TP-Link TL-SG1008P User Manual

1
Package Contents
The following items should be found in your box:
¾ One TL-SG1008P 8-Port Gigabit Desktop Switch with 4-Port
PoE
¾ One DC Power Adapter
¾ Four rubber cushions to be used under the Switch
¾ This User Guide
Note
Make sure that the box contains the above items. If any of the
listed items are damaged or missing, please contact your
distributor.

TP-Link TL-SG1008P Specifications

General

Switch type	Managed
Quality of Service (QoS) support	No
Power connector	DC-in jack
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Flow control support	Yes
Networking standards	IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3af, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Cable types supported	Cat3, Cat4, Cat5, Cat5e
Copper ethernet cabling technology	1000BASE-T, 100BASE-TX, 10BASE-T
Jumbo frames	16000
Forwarding rate	11.904 Mpps
MAC address table	4000 entries
Power source	DC/PoE
Input current	1.31 A
AC input voltage	100 - 240 V
DC input voltage	53.5 V
AC input frequency	50/60 Hz
Power consumption (max)	75 W
Number of power supply units	1
Product color	Gray
Housing material	Metal
Heat dissipation	225.75 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Total Power over Ethernet (PoE) budget	64 W
Power over Ethernet (PoE) ports quantity	4
Package type	Box
Package depth	280 mm
Package width	223 mm
Package height	68 mm
Package weight	900 g
Cables included	AC
Maximum cable length	100 m
Sustainability certificates	CE, Federal Communications Commission (FCC), RoHS

Weight and Dimensions

Depth	98 mm
Width	171 mm
Height	27 mm
