TP-Link TL-SG108 User Manual

8
Appendix A: Specifications
General
Standards IEEE802.3, IEEE802.3u, IEEE802.3ab
Topology Star
Protocol CSMA/CD
Ethernet: 10Mbps (Half Duplex)
20Mbps (Full Duplex)
Fast Ethernet: 100Mbps (Half Duplex)
200Mbps (Full Duplex)
Data Transfer Rate
Gigabit Ethernet: 2000Mbps (Full Duplex)
10Base-T:
UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
100Base-TX:
UTP category 5, 5e cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Network Media(Cable)
1000Base-T:
UTP category 5 cable (maximum 100m)
EIA/TIA-568 100Ω STP (maximum 100m)
Number of Ports
5 10/100/1000Mbps Auto-Negotiation RJ45 ports
(TL-SG105)
8 10/100/1000Mbps Auto-Negotiation RJ45 ports
(TL-SG108)

TP-Link TL-SG108 Specifications

General

Jumbo frames	16000
Forwarding rate	11.9 Mpps
MAC address table	4000 entries
Jumbo frames support	Yes
Packet buffer memory	1.5 MB
Maximum data transfer rate	2 Gbit/s
Supported data transfer rates	10/100/1000Mbps
10G support	No
Networking standards	IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Packet transfer speed	14880pps/148800pps/1488000pps
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Switch type	Unmanaged
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Switching protocols	CSMA/CD
Certification	CE, FCC, RoHS
Product color	Black
Rack mounting	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	191 mm
Package width	130 mm
Package height	92 mm
Package weight	510 g
Power source	DC
Input current	0.6 A
Input voltage	9 V
Power consumption (max)	3.31 W
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	101 mm
Width	158 mm
Height	25 mm
