TP-Link TL-SG108 User Manual

10
Appendix B: Troubleshooting
1. The Power LED is not lit
Check to see if the AC power cord is connected to the switch
properly, and make sure the power source is ON.
2. The Link/Act LED is not lit when a device is connected to the
corresponding port
Check to see if the cable connectors are firmly plugged into the
switch and the device, and verify the connected device is turned on
and working well. Make sure the cable is not longer than 100
meters (328 feet).

TP-Link TL-SG108 Specifications

General

Jumbo frames	16000
Forwarding rate	11.9 Mpps
MAC address table	4000 entries
Jumbo frames support	Yes
Packet buffer memory	1.5 MB
Maximum data transfer rate	2 Gbit/s
Supported data transfer rates	10/100/1000Mbps
10G support	No
Networking standards	IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Packet transfer speed	14880pps/148800pps/1488000pps
Connectivity technology	Wired
Ethernet interface type	Gigabit Ethernet
Switch type	Unmanaged
Power connector	DC-in jack
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
Switching protocols	CSMA/CD
Certification	CE, FCC, RoHS
Product color	Black
Rack mounting	-
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Package depth	191 mm
Package width	130 mm
Package height	92 mm
Package weight	510 g
Power source	DC
Input current	0.6 A
Input voltage	9 V
Power consumption (max)	3.31 W
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	101 mm
Width	158 mm
Height	25 mm
