TP-Link TL-SG108PE User Manual

Configuring VLAN Configuring 802.1Q VLAN
User Guide
51
802.1Q VLAN
Configuration
Enable or disable the 802.1Q VLAN mode.
2) Enter a VLAN ID and a VLAN name for identification. Select the untagged port(s) and the
tagged port(s) respectively to add to the created VLAN based on the network topology.
Click Add/Modify.
VLAN ID Enter a VLAN ID, which rages from 1 to 4094.
VLAN Name Enter a VLAN name for identification. The VLAN name should not be more
than 10 characters using digits, letters, hyphens and underlines only.
Untagged /
Tagged / Not
Member
Set the port as an untagged port, as a tagged port or not as a member port
in the VLAN.
Untagged: Select the egress rule of the port as Untagged. An untagged
port will forward frames after removing the VLAN tags.
Tagged: Select the egress rule of the port as Tagged. A tagged port will
forward frames with the current VLAN tags remained.
Not Member: The port that is not selected as a member will not forward
frames in the target VLAN.
3) In the table below, you can verify the configuration result of 802.1Q VLAN. You can
delete a VLAN as you wish by selecting the VLAN and clicking Delete.
Note:
•
By default, all the ports are added to VLAN 1.
•
The port can be removed from VLAN 1 only when the port is also a member of the other
VLANs.
•
Once a port is removed from all the current VLANs, it is added to VLAN 1 automatically.
•
VLAN 1 cannot be deleted.

TP-Link TL-SG108PE Specifications

General

Switch type	Managed
Switch layer	L2
Quality of Service (QoS) support	Yes
Installed SFP modules quantity	0
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	8
10G support	No
Number of VLANs	32
Networking standards	IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ab, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x
Virtual LAN features	Port-based VLAN
Cable types supported	Cat3, Cat4, Cat5, Cat5e, Cat6
Total Power over Ethernet (PoE) budget	64 W
Power over Ethernet (PoE) ports quantity	4
Power over Ethernet (PoE) power per port	15.4 W
Jumbo frames	15000
Forwarding rate	11.9 Mpps
MAC address table	4000 entries
Packet buffer memory	1.5 MB
Power source	DC
Input current	1.25 A
Input voltage	48 V
Power consumption (max)	65.2 W
Certification	FCC, CE, RoHS
Product color	Black
Rack mounting	-
LED indicators	Activity, Link, PoE, Power, Speed, Status
Package type	Box
Package depth	196 mm
Package width	131 mm
Package height	121 mm
Package weight	890 g
Cables included	AC
Heat dissipation	256.19 BTU/h
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 95 %
Operating relative humidity (H-H)	10 - 90 %
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	101 mm
Width	158 mm
Height	25 mm
