30 MS-SVN056C-EN
Outdoor Unit Installation
Outdoor Unit Installation
Location
The unit must be installed in a place that complies with the following requirements:
•Full clearance for installation and maintenance procedures
• Unobstructed inlets and outlets and also free of outdoor air currents
• Dry and well vented location
• Mounting foundation should be capable of supporting the weight of the outdoor unit and
prevent the transmission of noise and vibrations
• Easy access to piping and wiring installations
• Unobstructed outlet for discharge air
• Free from fire hazard due to gas leaks
• Piping length between the outdoor unit and indoor unit not to exceed allowable dimensions
• If location is exposed to strong winds, the unit is to be installed against the wall or should be
protected against strong winds.
• If possible, unit should not be exposed to direct sun rays
• Placing outdoor unit as close as possible to the indoor unit
