Accessories provided for installation
Concealed unit
19. Screen connecting cable (2M)
20. Cable protecting sheath
.
QUANTITY
DRAWING
NAME
1. Tubular insulation
11. Remote control manual
7. Remote control unit
(in some models)
8. Remote control housing
10.Battery AAA 1.5V
2
1
12. Wired controller
1
1
1
1
(some models)
2
1
1
1
9.Mounting screws (ST2.9×10-C-H)
15. Installation Manual
16. Connector transfer. (ĭ12.7-ĭ15.9)/
( )
(packed together with unit)
(NOTE: Tube size differs depending on
model. Connector is needed to comply
with tube size requirements for outdoor
unit installation).
17 .Connector transfer.( ĭ6.35-ĭ9.52)

(packed together with unit)
(NOTE: Tube size differs depending on
model. Connector is needed to comply
with tube size requirements for outdoor
unit installation).
18 .Connector transfer. (ĭ9.52-ĭ12.7)/
( )
(packed together with unit, used only
on multi-type models)
(NOTE: Tube size differs depending on
model. Connector is needed to comply
with tube size requirements for outdoor
unit installation).
1
14. User Manual
5. Drain cap
6. Grommet
2. Insulating tape
1
3. Protective sponge
2
13. Magnetic ring
(twist electric wires L and N around
magnetic ring performing 5 turns)
1
L N
4. Orifice plate
1
(some models)
ĭ0.5in-ĭ0.63in
ĭ0.25in-ĭ0.375in
ĭ0.375in-ĭ0.5in
1
(some models)
1
(some models)
1
(some models)
1
(some models)
1
(some models)
