Determine Unit Clearances
Figure 1. Space on Sides Requirements
DDDD
CC
EE D
BB
A
FF
FRONT SIDE
LEFT SIDE
BOTTOM SIDE
TOP SIDE
W/ ECONOMIZER W/ ECONOMIZER
BACK SIDE 305 [12] 762 [30] 305 [12] 762 [30]
LEFT SIDE 762 [30] 914 [36] 914 [36] 1067 [42]
RIGHT SIDE 914 [36] - 914 [36] -
FRONT SIDE 1067 [42] - 1067 [42] -
BOTTOM
BACK SIDE
LEFT SIDE
RIGHT SIDE
FRONT SIDE
TOP
A
BB
CC
CENTER OF GRAVITY - TABLE NEXT PAGE
CENTER OF GRAVITY - TABLE NEXT PAGE
305 [12] 305 [12]
914 [36] 914 [36]
DIMENSIONS mm [Inches]
HEIGHT OF UNIT - TABLE NEXT PAGE
25 [1] 25 [1]
152 [6] 152 [6]
305 [12] 305 [12]
2 - 3 TON Units 3.5 - 5 TON Units
RECOMMENDED SERVICE CLEARANCE mm [Inches]
CLEARANCE TO COMBUSTIBLE MATERIAL mm [Inches]
0 0
DD -Depth
EE -Width
FF 498.90 [19-5/8] 575.06 [ 22-5/8]
1095.00 [43-1/18] 1169.92 [46-1/16]
1531.87 [60-5/16]
1284.99 [50-19/32]
D
134.94 [5-5/16]
135.39 [5-11/32]
Note: The view labeled “Bottom side”
represents the base as viewed looking
up from underneath the unit.
