18-GF16D1-1A-EN
11
Performance and Electrical Data
Table 3. Air Flow Performance
A4AH4E24A1B60A
EXTERNAL STATIC
(in w.g)
AIRFLOW
Speed Taps: 208 – 230 VOLTS
High Med-High
Med † Low
0.1 1140 1078 930 851
0.2 1087 1017 870 796
0.3 1034 955 807 733
0.4 978 894 741 663
0.5 922 834 671 584
0.6 863 774 597 497
0.7 804 715 519 403
1. Values are with wet coil, no filter, and no heaters
2. CFM Correction for dry coil = Add 3%
3. † = Factory Setting
4. Low = Taps 1–2, Med = Tap 3, Med-High= Tap 4, High = Tap 5
Table 4. Electrical Data
A4AH4E24A1B60A
Heater Model No.
No. of
Circuits/
Phases
240 Volt 208 Volt
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
Protection
Capacity
Heater
Amps per
Circuit
Minimum
Circuit
Ampacity
Maximum
Overload
ProtectionkW BTUH kW BTUH
No Heater 2.8 * 4 15 2.8 * 4 15
BAYHTR1504BRK
BAYHTR1504LUG
1/1
3.8 13100 16.0 24 25 2.9 9800 13.8 21 25
BAYHTR1505BRK
BAYHTR1505LUG
1/1
4.8 16400 20.0 29 30 3.6 12300 17.3 25 25
BAYHTR1508BRK
BAYHTR1508LUG
1/1
7.7 26200 32.0 44 45 5.8 19700 27.7 38 40
BAYHTR1510BRK
BAYHTR1510LUG
1/1
9.6 32800 40.0 54 60 7.2 24600 34.6 47 50
BAYHTR3510LUG
1/3
9.6 32800 23.1 32 35 7.2 24600 20.0 28 30
* = Motor Amps
