Heater Pressure Drop Table
Airflow
CFM
Number of Racks Heater Racks
1 2 3 4 Heater Model No. of Racks
Air Pressure Drop — Inches W.G.
BAYHTR1504 1
1800 0.02 0.04 0.06 0.14 BAYHTR1505 1
1700 0.02 0.04 0.06 0.14 BAYHTR1508 2
1600 0.02 0.04 0.06 0.13 BAYHTR1510 2
1500 0.02 0.04 0.06 0.12 BAYHTR1517 3
1400 0.02 0.04 0.06 0.12 BAYHTR3510 3
1300 0.02 0.04 0.05 0.11 BAYHTR3517 3
1200 0.01 0.04 0.05 0.10 BAYHTR3515 3
1100 0.01 0.03 0.05 0.09 BAYHTR1523 4
1000 0.01 0.03 0.04 0.09 BAYHTR1525 4
900 0.01 0.03 0.04 0.08
800 0.01 0.03
700 0.01 0.02
600 0.01 0.02
Subcooling Adjustment
System Matched with: Indoor Unit Model No. Outdoor Model No. Subcooling
16 SEER HP — 2 ton A4AH5V36A1C30 4TWR6024H1
4TWX6024H1
4A6H6024H1
A4HP6024A1
13 Degrees
15 SEER HP — 2 ton A4AH5V24A1B30
A4AH5V30A1B30
4TWR5024G1
4A6H5024G1
A4HP6024A1
14 Degrees
15 SEER HP — 3 ton A4AH5V30A1B30
A4AH5V36A1C30
A4AH5V42A1C30
4TWR5036G1
4A6H5036G1
A4HP6036A1
4A6H5036N1
4TWR5036N1
A4HP5036D1
4TWX5036N1
14 Degrees
All other matches must be charged per the nameplate charging instructions
Subcooling Adjustment for A4AH5V48A1 and A4AH5V60B1
Sub-Cooling Charge Specification For AHRI Rated Performance
OD Equipment Up Flow / Horizontal Down Flow
AC UNIT OD Name Plate OD Name Plate
HP UNIT ≤ 3.5 Tons OD Name Plate OD Name Plate
+ 4 Degrees
HP UNIT = 4 and 5 Tons OD Name Plate OD Name Plate
