Trane AUD1A040A9H21B User Manual

Installer’s Guide
18-CD21D1-12
SEE
NOTE 6
From Dwg. B341437 Rev. 1
FURNACE
TWIN
SEE
NOTE 7
B/C
B/C
TO 115 V 1 PH.,
60 HZ., POWER
SUPPLY PER
LOCAL CODES
HUM SEE
NOTE 5
EAC SEE
NOTE 5
FIELD WIRING DIAGRAM FOR 1 STAGE FURNACE
1 STAGE HEATING
USING A 1 STAGE HEATING THERMOSTAT
NO COOLING
From Dwg. 21B341437 P01
OUTDOOR UNIT
(NO TRANSFORMER)
SEE
NOTE 6
From Dwg. B341436 Rev. 1
SEE
NOTE 8
FURNACE
TWIN
SEE
NOTE 7
B/C
B/C
TO 115 V 1 PH.,
60 HZ., POWER
SUPPLY PER
LOCAL CODES
HUM SEE
NOTE 5
EAC SEE
NOTE 5
FIELD WIRING DIAGRAM FOR 1 STAGE FURNACE
1 STAGE HEATING, 1 STAGE COOLING
USING A 1 STAGE HEATING, 1 STAGE COOLING THERMOSTAT
(OUTDOOR SECTION WITHOUT TRANSFORMER)
From Dwg. 21B341436 P01

Trane AUD1A040A9H21B Specifications

General

Brand	Trane
Model	AUD1A040A9H21B
Category	Furnace
Language	English
