Appendix B. CenTraVac™™ Chiller Installation
Completion and Request for Trane Service
IImmppoorrttaanntt:: A copy of this completed form must be
submitted to the Trane Service Agency that
will be responsible for the start-up of the
chiller. Start-up will NOT proceed unless
applicable items listed in this form have
been satisfactorily completed.
TO:
TRANE SERVICE OFFICE:
S.O. NUMBER:
SERIAL NUMBERS:
JOB/PROJECT NAME:
ADDRESS:
The following items
are being installed
and will be completed by:
IImmppoorrttaanntt:: Start-up must be performed by Trane or an
agent of Trane specifically authorized to
perform start-up and warranty of Trane
®
products. Contractor shall provide Trane
(or an agent of Trane specifically
authorized to perform start-up) with notice
of the scheduled start-up at least two weeks
prior to the scheduled start-up. EEqquuiippmmeenntt
nnoott ssttaarrtteedd bbyy TTrraannee iiss nnoott wwaarrrraanntteedd bbyy
TTrraannee..
NNootteess:: Improper installation of CenTraVac
™ chillers,
including optional components, can result in
start-up delay and required rework. Follow all
provided instructions and in use particular care
with optional devices:
• Follow installation procedures for
RuptureGuard
™ ; refer to CTV-SVX06*-EN
for CDHF, CDHG, CVHE, CVHF, CVHG, CVHL,
and CVHS models, refer to CDHH-SVX001*-
EN for CDHH models, and refer to CVHH-
SVX001*-EN for CVHH CenTraVac
™ chiller
models.
• Do NOT over-insert or over-torque the probe
of the ifm efector
™ flow detection controller
and sensor; refer to PART-SVN223*-EN or
the CenTraVac
™ chiller Installation,
Operation, and Maintenance manual.
• Do NOT block serviceable parts when
installing isolation springs.
Expenses that result in improper installation of
CenTraVac
™ chillers, including optional
components, will NOT be paid by Trane.
Check box if the task is complete or if the answer is
“yes”.
1. CCeennTTrraaVVaacc™™ CChhiilllleerr
In place and piped.
NNoottee:: Do not insulate the CenTraVac
™ chiller or
adjacent piping prior to the chiller
commissioning by Trane service personnel.
The contractor is responsible for any foreign
material left in the unit.
2. PPiippiinngg
Chilled water piping connected to:
CenTraVac™ chiller
Air handling units
Pumps
Optional ifm efector® flow detection controller
and sensor properly installed
Condenser and heat recovery condenser (as
applicable) piping connected to:
CenTraVac™ chiller
Pumps
Cooling tower
Heating loop (as applicable)
Additional piping:
Make-up water connected to cooling tower
Water supply connected to filling system
Systems filled
Pumps run, air bled from system
Strainers cleaned
Rupture disk or RuptureGuard™ ventilation
piping properly installed
Optional RuptureGuard™ properly installed
3. FFllooww bbaallaanncciinngg vvaallvveess iinnssttaalllleedd
Leaving chilled water
Leaving condenser water
Optional heat recovery or auxiliary condenser
water
4. GGaauuggeess,, tthheerrmmoommeetteerrss,, aanndd aaiirr vveennttss
Installed on both sides of evaporator
Installed on both sides of condenser and heat
recovery condenser (as applicable)
5. WWiirriinngg
Compressor motor starter has been furnished
by Trane, or has been configured and installed
in compliance with the appropriate Trane
Engineering Specification for Starter by Others
(available from your local Trane Sales Office)
Full power available
