CVHE-SB-32A 64
Table 14
Purge Compressor Suction Temp.
Al Analog Input
Thermistor Accuracy = 0.54°°F from -14 to 79°°F
Type U Thermistor Temperature Versus Resistance and Terminal Voltage Table for a
pullup resistor of 24900 Ohms.
Used to sense temperatures at the following point:
1. Purge Compressor Suction Temp. CVHE/F/G
Temp °°F Min Res Max Res Min Vterm Max Vterm
-10.0 119172 123480 4.115 4.145
-5.0 101107 104703 3.992 4.024
-4.0 97868 101337 3.966 3.999
-3.0 94743 98090 3.940 3.973
-2.0 91726 94957 3.913 3.946
-1.0 88816 91934 3.886 3.920
0.0 86006 89016 3.858 3.893
1.0 83293 86199 3.830 3.865
2.0 80675 83480 3.802 3.837
3.0 78146 80855 3.773 3.809
4.0 75705 78320 3.743 3.780
5.0 73347 75873 3.714 3.751
10.0 62706 64832 3.560 3.600
15.0 53738 55532 3.399 3.441
16.0 52119 53854 3.366 3.408
17.0 50554 52231 3.332 3.375
18.0 49040 50663 3.299 3.341
19.0 47577 49145 3.265 3.308
20.0 46161 47678 3.231 3.274
25.0 39742 41029 3.058 3.102
30.0 34292 35386 2.881 2.926
35.0 29713 30628 2.705 2.750
40.0 25830 26611 2.532 2.577
45.0 22512 23180 2.361 2.405
50.0 19668 20242 2.194 2.237
55.0 17225 17718 2.033 2.075
60.0 15120 15546 1.879 1.919
65.0 13303 13670 1.731 1.770
70.0 11729 12048 1.592 1.629
75.0 10364 10641 1.462 1.496
