CVHE-SB-32A 73
Table 19
Auxiliary HR Ent. and Condenser Ent. and Leaving Water Temp.
A2 Analog Input
Thermistor Accuracy = 0.54°°F from 15 to 140°°F
Type U Thermistor Temperature Versus Resistance and Terminal Voltage Table for a
pullup resistor of 6980 Ohms.
Used to sense temperatures at the following point:
1. Auxiliary HR Entering and Leaving Water Temp. Pair CVHE/F
2. Condenser Ent. and Leaving Water Temp. Pair CVHE/F
Table 19
Temp F Min Res Max Res Min Vterm Max Vterm
15546 15120 15546 3.404 3.441
61.0 14735 15148 3.376 3.413
62.0 14361 14762 3.348 3.385
63.0 13998 14388 3.319 3.357
64.0 13645 14024 3.291 3.329
65.0 13303 13670 3.262 3.300
66.0 12970 13327 3.233 3.272
67.0 12646 12993 3.204 3.243
68.0 12332 12669 3.175 3.214
69.0 12026 12354 3.146 3.185
70.0 11729 12048 3.117 3.156
71.0 11441 11750 3.088 3.127
72.0 11160 11461 3.058 3.098
73.0 10887 11180 3.029 3.068
74.0 10622 10907 2.999 3.039
75.0 10364 10641 2.970 3.010
76.0 10113 10383 2.940 2.980
77.0 9870 10131 2.911 2.951
78.0 9632 9887 2.881 2.921
79.0 9402 9649 2.851 2.891
80.0 9177 9418 2.822 2.862
81.0 8959 9193 2.792 2.832
82.0 8746 8974 2.763 2.803
83.0 8539 8761 2.733 2.773
84.0 8338 8554 2.704 2.744
85.0 8142 8353 2.674 2.714
