ACC-SVN232A-EN 5
General Information
Inspection
1. Unpack all components of the kit.
2. Check carefully for shipping damage. If any damage is
found, report it immediately, and file a claim against
the transportation company.
3. Visually inspect the components for shipping damage
as soon as possible after delivery, before it is stored.
Concealed damage must be reported within 15 days.
4. If concealed damage is discovered, stop unpacking the
shipment.
Parts List
Field Installed Option
5. Do not remove damaged material from the receiving
location. Take photos of the damage, if possible. The
owner must provide reasonable evidence that the
damage did not occur after delivery.
6. Notify the carrier’s terminal of damage immediately by
phone and by mail. Request an immediate joint
inspection of the damage by the carrier and the
consignee.
Note: Do not attempt to repair any damaged parts until
the parts are inspected by the carrier’s
representative.
Factory Installed Option
Figure 1. Major economizer components
Item Description Qty
1 Outside air damper assembly 1
2 Connecting rod assembly 2
3 Return air damper assembly 1
4Block-off 1
5 Plastic bag of miscellaneous parts 1
Screws
Edge protector 1
Installation Instructions manual 1
6Rain diverter 1
Note: Verify all the parts are available for installation.
Item Description Qty
1Block-off 1
2 Plastic bag containing
1
Screws
