6
PTAC-SVX004A-EN
General Information
The ProSpace™ Packaged Terminal Air Conditioners
and heat pumps provide a high standard of quality in
performance, workmanship, durability and appearance
as they heat and cool the occupied air space year
round.
This manual provides information for ease of
installation, operation and maintenance. All models are
designed for through–the–wall installation. Separate
installation instructions are included with all accessory
components.
Read this manual completely and carefully before
starting any work. Write down the model and serial
number on the space provided on the product
registration card. The model and serial number can be
located on the serial number plate attached to the unit.
These numbers are required for any service work.
IImmppoorrttaanntt:: Ensure that this manual is left with the
owner for future reference. Observe all
local codes and ordinances. Observe all
governing codes and ordinances. These
instructions must be saved for local
inspector's use. Be sure to leave these
instructions with the owner.
Table 1. Operating Temperature Range:
Indoor Side DB/WB (°F/°C) Outdoor Side DB/WB (°F/°C)
Maximum Cooling 80/67 (26.7/19.4) 115/75 (46.1/23.9)
Maximum RC Heating 80/- (26.7/-) 75/65 (23.9/18.3)
Maximum Electric Heating 77/- (25/-) 77/- (25/-)
• Ambient temperature range (indoor temperature) for cooling is 64-80°F (18-26.7°C),
• Ambient temperature range (outdoor temperature) for cooling is 64-115°F (18-46.1°C),
• Ambient temperature range (indoor temperature) for heat pump is 41-80°F (5-26.7°C),
• Ambient temperature range (outdoor temperature) for Electric Heating is 19-77°F (-7-25°C).
• Ambient temperature range (outdoor temperature) for heat pump is 55-75°F (13-23.9°C),
