Trane ProSpace PTHG1201HAA User Manual

PTAC-SVX004A-EN
9
Heat Pumps with Electric Heaters
Performance Units
PTHG0701GAA PTHG0702GAA PTHG0901GAA PTHG0902GAA PTHG1201HAA PTHG1202HAA PTHG1501HAA PTHG1502HAA
Trade Name:
ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™ ProSpace™
Style/Function:
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Heat Pump w/
Heaters
Cooling
Capacity:
Btu/h 7,200/7,400 7,300 9.400/9,700 9,800 11,900/12,100 12,000 14,200/14,600 14,500
Heating
Capacity:
Btu/h 5,800/6,000 6,000 8,200/8,500 8,600 10,700/10,900 10,700 13,300/13,800 13,300
Electric Heat
Power Input
Only:
W
2,450(2,010)/
3,450(2,830)
2,450/3,450
2,450(2,010)/
3,450(2,830)
2,450/3,450
2,450(2,010)/ 3,450(2,830)/
5,000(4,090)
2,450/3,450/
5,000
2,450(2,010)/ 3,450(2,830)/
5,000(4,090)
2,450/3,450/
5,000
Rated Input
(Electric Heat +
Fan Motor)
W
2,500(2,040)/
3,500(2,860)
2,500/3,500
2,500(2,040)/
3,500(2,860)
2,500/3,500
2,500(2,040)/ 3,500(2,860)/
5,050(4,130)
2,500/3,500/
5,050
2,500(2,040)/ 3,500(2,860)/
5,050(4,130)
2,500/3,500/
5,050
EER:
(Btu/h)/
W
13.0 13.0 12.1 12.1
11.8/11.6
11.6 10.4 10.4
Dehumidifying
Vol:
Pint/h
1.69 1.69 2.11 2.11 2.75 2.75 3.17 3.17
Application
Area:
ft2 108-172 108-172 129-194 129-194 172-258 172-258 226-334 226-334
Electrical
Rated Voltage:
V~
208/230
265
208/230
265
208/230
265
208/230
265
Rated
Frequency:
Hz 60 60 60 60 60 60 60 60
Phases: 1 1 1 1 1 1 1 1
Cooling Power
Current:
A
2.6/2.4
2.1
3.9/3.6
3.1
4.9/4.6
4.0
6.5/6.0
5.3
Heating Power
Current:
A
2.3/2.1
1.8
3.2/3.1
2.6
4.3/4.1
3.5
5.9/5.6
4.7
Power Cord:
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Refer to Table 2
and Table 3.
Features
Sound Pressure
Level (L/H):
dB (A)
46/50 46/50 46/50 46/50 50/53 50/53 50/53 50/53
Airflow Volume
(L/H):
CFM
282/312 282/312 282/330 282/330 306/341 306/341 306/341 306/341
Warranty:
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
5-Year Parts/5-
Year Sealed
System
Replacement
Specifications
Dim of Package
(L x W x H):
Inch 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19 45 x 25 x 19
Net Weight:
lb 112 112 115 115 119 119 120 120
Refrigerant:
R32 R32 R32 R32 R32 R32 R32 R32
Refrigerant
Charge:
lb 1.7 1.7 1.5 1.5 1.8 1.8 1.9 1.8
