RTAC-SVX002A-EN 3
R T A C 3 5 0 J B A 0 N N 0 F N N A T Y 2 N D C N N 0 N N 1 0 N N 0 P N N 0 0 0 0 N
1 2 3 4 5 6 7 8 9 10 1 1 12 13 14 15 16 17 1 8 19 20 21 22 23 24 2 5 26 27 28 29 30 31 3 2 33 34 35 36 3 7 38 39 40 41 42
I-Model Number
Digits 1, 2 - Unit Model
RT = "Rotary Chiller"
Digit 3 - Unit Type
A = Air Cooled
Digit 4 - Project Sequence
C = Sequence C
Digits 5, 6 e 7 - Nominal Capacity
140 = 140 Nominal Tons
155 = 155 Nominal Tons
170 = 170 Nominal Tons
185 = 185 Nominal Tons
200 = 200 Nominal Tons
225 = 225 Nominal Tons
250 = 250 Nominal Tons
275 = 275 Nominal Tons
300 = 300 Nominal Tons
350 = 350 Nominal Tons
Digit 8 - Power Supply
C = 230/60/3
J = 380/60/3
D = 380-400/50/3
4 = 440-460/60/3
Digit 9 - Manufactoring Location
B = Curitiba Unit - Brazil
Digits 10, 11 - Minor Design Sequence
A0 - Sequence A0 (Factory Dened)
Digit 12 - Unit Basic Conguration
N = Standard efciency/performance
conguration
H = High efciency/performance
conguration
Digit 13 - Agency Listing
N = no agency listing
Digit 14 - Pressure vessel code
0 = no codication
Digit 15 - Evaporator Temperature Range
F = Standard (40-60°F)
G = Low Temp. (less than 40°F)
Digit 16 - Evaporator Cong
N = Standard
Digit 17 - Condenser application
N = Standard Temp. (25-115°F)
L = Low Temp (0-115°F)
Digit 18 - Condensador Fin Material
A = Aluminun Standard
Y = Aluminum Yellow Fin
Digit 19 - Condenser Fan/Motor
Conguration
T = Standard Fan with IPW55/TEAO motor
W = Low Noise Fans
Digit 20 - Compressor Starter Type
Y = Y-delta closed transition starter
Digit 21 - Incoming Power Line
Connection
1 = Single point power connection
2 = Dual point power connection
Digit 22 - Power line connection type
N = Input power bar
D = Non-fused disconnect switch for
incoming line
C = Circuit breacker for incoming line
Digit 23 - Unit operator interface
D = Dynaview
P = With protection box Dynaview
Digit 24 - Remote operator interface
N = w/o remote operator interface
C = Tracer Comm3 Interface
L = Comm5 - LonTalk Compatible (LCI-C)
Interface
Digit 25 - Input Controls
N = w/o control
R = Ext. evaporator leaving water setpoint
C = Current Demand Control
B = External setpoint and e Current Demand
Control
Digit 26 - Output Controls
N = w/o control
A = Alarme relay output
C = Output Relay Icemaking
D = Alarm relay outputs and icemaking
Digit 27 - Reserved Digit
0 = Reserved
Digit 28 - Electrical Accessories
N = w/o Accessories
E = Nema-1 Flow Switch - 150 psi
Digit 29 - Electrical Board Accessories
N = w/o Accessories
Digit 30 - Service Valve
1 = Succion Service Valve
Digit 31 - Sound attenuator
0 = w/o sound attenuator
1 = w/ sound attenuator
Digit 32 - Panel Protection
N = w/o protection
A = Total Protection Panels
C = Coil Protection Panels
Digit 33 - Installation Accessories
N = w/o installation accessories
R = Neoprene Vibration Isolators
F = Flange kit for water connections
G = Neoprene Isolator and Flange Kit
Digit 34 - Reserved Digit
0 = Reserved
Digit 35 - Language - Literature/Stickers
P = Portuguese/Spanish
Digit 36 - Shipping Facility Accessories
0 = Reserved
Digit 37 - Security Devices
N = Standard
Digit 38 - Reserved Digit
0 = Reserved
Digit 39 - Reserved Digit
0 = Reserved
Digit 40 - Reserved Digit
0 = Reserved
Digit 41 - Reserved Digit
0 = Reserved
Digit 42 - Product Type
N = Standard
Z = Special
