RTAC-SVX002A-EN 33
IV-Installation Electrical
General Recommendations
All wiring must comply with local codes
and the National Electric Code. Typical
eld wiring diagrams are included at
the end of the manual. Minimum circuit
ampacities and other unit electrical data
are on the unit nameplate. See the unit
order specications for actual electrical
data. Specic electrical schematics and
connection diagrams are shipped with
the unit.
WARNING
Hazardous Voltage w/Capacitors!
Disconnect all electric power,
including remote disconnects before
servicing. Follow proper lockout/
tagout procedures to ensure the
power cannot be inadvertently
energized. For variable frequency
drives or other energy storing
components provided by Trane
or others, refer to the appropriate
manufacturer’s literature for
allowable waiting periods for
discharge of capacitors. Verify with
an appropriate voltmeter that all
capacitors have discharged. Failure
to disconnect power and discharge
capacitors before servicing could
result in death or serious injury.
Note: For additional information
regarding the safe discharge of
capacitors, see PROD-SVB06A-EN or
PROD-SVB06A-FR
CAUTION
Use Copper Conductors Only!
Unit terminals are not designed to
accept other types of conductors.
Failure to use copper conductors
may result in equipment damage.
Important!
Do not allow conduit to interfere
with other components, structural
members or equipment. Control
voltage (115V) wiring in conduit must
be separate from conduit carrying
low voltage (<30V) wiring.
Caution: To prevent control
malfunctions, do not run low
voltage wiring (<30V) in conduit with
conductors carrying more than 30
volts.
