RTAC-SVX002A-EN 82
VII-Diagnostics
Tab. VI-01 – Setpoints View Items
Hex
Code
Diagnostic Name and
Source
Severity Persistence Criteria Reset Level
398 BAS Communication Lost Special NonLatch The BAS was setup as “installed” at the MP and the Comm 3 LLID lost
communications with the BAS for 15 contiguous minutes after it had been
established. Refer to Section on Setpoint Arbitration to determine how
setpoints and operating modes may be effected by the comm loss. The
chiller follows the value of the Tracer Default Run Command which can
be previously written by Tracer and stored nonvolatilely by the MP (either
use local or shutdown).
Remote
390 BAS Failed to Establish Special NonLatch The BAS was setup as “installed” and the BAS did not communicate with
the MP within 15 minutes after power-up. Refer to Section on Setpoint
Arbitration to determine how setpoints and operating modes may be
effected. Note: The original requirement for this was 2 minutes, but was
implemented at 15 minutes for RTAC
Remote
2E6 Check Clock Info Latch The real time clock had detected loss of its oscillator at some time in
the past. This diagnostic can be effectively cleared only by writing a new
value to the chiller's time clock using the TechView or DynaView's
"set chiller time" functions.
Remote
8A Chilled Water Flow
(Entering
Info NonLatch The entering evaporator water temp fell below the leaving evaporator
water temp. by more than 2°F for 100 °F-sec. For RTAC this diagnostic
cannot reliably indicate loss of ow, but can warn of improper ow
direction through the evaporator, misbound temperature sensors, or
other system problems
Remote
5EF Comm Loss: Chilled
Water Flow Switch
Latch Continual loss of communication between the MP and the Immediate
Functional ID has occurred for a 30 second period.
Remote
5F2 Comm Loss: Cond Rfgt Pressure, Circuit #1 Immediate Latch Same as Comm Loss: Chilled Water Flow Switch Remote
694 Comm Loss: Electronic
Expansion Valve, Circuit
#1
Normal Latch Same as Comm Loss: Chilled Water Flow Switch Remote Remote
695 Comm Loss: Electronic
Expansion Valve, Circuit
#2
Normal Latch Same as Comm Loss: Chilled Water Flow Switch Remote Remote
5DE Comm Loss: Emergency
Stop
Normal Latch S Same as Comm Loss: Chilled Water Flow Switch Remote Stop Remote
68E Comm Loss: Evap Oil
Return Valve, Cprsr 1A
Normal Latch Same as Comm Loss: Chilled Water Flow Switch Remote Remote
69E Comm Loss: Evap Oil
Return Valve, Cprsr 1B
Normal Latch Same as Comm Loss: Chilled Water Flow Switch Remote
68F Comm Loss: Evap Oil
Return Valve, Cprsr 2A
Normal
Latch Same as Comm Loss: Chilled Water Flow Switch Remote
69F Comm Loss: Evap Oil
Return Valve, Cprsr 2B
Normal Latch Same as Comm Loss: Chilled Water Flow Switch Remote
5E4 Comm Loss: Evaporator
Entering Water
Temperature
Special Latch Same as Comm Loss: Chilled Water Flow Switch Remote
5E3 Comm Loss: Evaporator
Leaving Water
Temperature
Normal Latch Same as Comm Loss: Chilled Water Flow Switch Remote
6BB Comm Loss: Evaporator
Rfgt Drain Valve - Ckt 1
Normal Latch Same as Comm Loss: Chilled Water Flow Switch Remote
6BC Comm Loss: Evaporator
Rfgt Drain Valve - Ckt 2
Normal Latch Same as Comm Loss: Chilled Water Flow Switch Remote
688 Comm Loss: Evaporator
Rfgt Liquid Level, Circuit
#1
Immediate Latch Same as Comm Loss: Chilled Water Flow Switch Remote
689 Comm Loss: Evaporator
Rfgt Liquid Level, Circuit
#2
Immediate Latch Same as Comm Loss: Chilled Water Flow Switch Remote
5F0 Comm Loss: Evaporator
Rfgt Pressure, Circuit #1
Immediate Latch Continual loss of communication between the MP and he Functional ID
has occurred for a 30 second period.
Note: This diagnostic is replaced by diagnostic 5FB below with Rev 15.0
Remote
5F1 Comm Loss: Evaporator
Rfgt Pressure, Circuit #2
Immediate Latch Continual loss of communication between the MP and the Functional ID
has occurred for a 30 second period. Note: This diagnostic is replaced
by diagnostic 5FD below with Rev 15.0
Remote
