RTWB-SVN01B-E4
18
General recommendations
For proper electrical component
operation, do not locate the unit in
areas exposed to dust, dirt,
corrosive fumes, or excessive
humidity. If any of these conditions
exist, corrective action must be
taken.
WWAARRNNIINNGG
Disconnect all electrical power,
including remote disconnects,
before servicing. Failure to
disconnect power before servicing
can cause severe personal injury or
death.
Table 7 – Electrical data
RTWB 207 208 210 211 212 214 216 217 218 220 222 224
Nominal voltage (V) 400 400 400 400 400 400 400 400 400 400 400 400
Frequency (Hz) 50 50 50 50 50 50 50 50 50 50 50 50
(V) Mini 360 360 360 360 360 360 360 360 360 360 360 360
Maxi 440 440 440 440 440 440 440 440 440 440 440 440
Max. unit kW (kW) 90 106 132 142 152 182 202 222 243 264 292 320
(A) 147 170 215 235 255 297 329 360 396 432 477 521
Starting Amps (1) (A) 170 196 228 264 279 332 374 398 430 457 520 554
Power factor 0.91 0.92 0.90 0.89 0.88 0.89 0.90 0.90 0.89 0.89 0.89 0.89
Fuse size (2) 80A 100A 125A 60/125 160A 2*160 160+200 2*200 250+200 2*250 2*315 2*315
(A) 315 315 315 400 400 400 630 630 630 630 800 800
mm² 240 240 240 240 240 240 2*300 2*300 2*300 2*300 2*300 2*300
(1) Star delta start. Maximum starting Amps: one compressor at full load, the other one starting.
(2) With disconnect switch option
(3) mm²/phase
Note: To prevent control malfunctions, do not run low-voltage wiring (<30V) in conduits with conductors carrying more than 30 V.
All wiring must comply with
national electrical regulations.
Electrical characteristics and other
unit electrical data are on the unit
nameplate. Specific electrical
schematics and connection
diagrams are shipped with the unit.
Use copper conductors only. Unit
terminals are not designed to accept
other types of conductors. Failure to
do so may cause damage to the
equipment.
Do not allow conduits to interfere
with other components, structural
members, or equipment. All
conduits must be long enough to
allow compressor and starter
removal.
Installation Electrical
Maximum connecting
wire (2)(3)
Maximum Rated
Load Amps
Voltage utilization
range
Disconnect
switch size
