Trane Tracer ZN524 User Manual

CNT-SVX11A-EN 43
Appendix
Resistance (
VV
) Setpoint (°F)
889.4 50
733.6 58
577.9 66
500 70
422.1 74
344.2 78
266.4 82
188.5 86
110.6 90
Hardwired Setpoint Adjustment
Table 26: Hardwired setpoint adjustment
Fan Switch Resistance Values
Table 27: Resistance Values
Resistance (
VV
) Switch Position
16,300 High
10,700 Low
2,320 Auto
4,870 Off
Resistance (
VV
) Temperature
87.5kV 0°F
74.6kV 5°F
63.8kV 10
°F
54.6kV 15°F
46.9kV 20°F
40.4kV 25
°F
34.8kV 30°F
30.2kV 35°F
26.2kV 40
°F
22.8kV 45
°F
20.0kV 50°F
17.5kV 55
°F
15.3kV 60
°F
13.5kV 65°F
11.9kV 70
°F
10.5kV 75°F
Resistance (
VV
) Temperature
10.0kV 77°F
9.3kV 80°F
8.2kV 85°F
7.3kV 90°F
6.5kV 95°F
5.8kV 100°F
5.2kV 105
°F
4.7kV 110 °F
4.2kV 115 °F
3.8kV 120
°F
3.4kV 125
°F
3.1kV 130°F
2.8kV 135
°F
2.5kV 140
°F
2.3kV 145°F
2.1kV 150°F
Hardwired Thermistor Values
Table 28: Hardwired 10k V thermistor values
