CNT-SVX11A-EN 45
Appendix - Unit
Operation
Unit Operation Based On The Effective H
EAT/C
OOL Output
Table 30: Unit operation based on H EAT
/C OOL ouput
Application Heat/cool mode input Effective heat/ cool Unit Operation
mode input
(nviHeatCool) mode output
(nviApplicMode) (nvoHeatCool)
Auto Determined by controller Fan—Enabled
Heating—Enabled
Cooling—Enabled
Damper—Enabled
Heat Heating Fan—Enabled
Heating—Enabled
Cooling—Disabled
Damper—Enabled
Morning warm up Pre-heat Fan—Enabled
Heating—Enabled
Cooling—Disabled
Damper—Disabled
Cooling Cooling Fan—Enabled
Heating—Disabled
1
Cooling—Enabled
Damper—Enabled
Auto Pre-cool Pre-cool Fan—Enabled
Heating—Disabled
1
Cooling—Enabled
Damper—Disabled
Off Off Fan—Disabled
Heating—Disabled
Cooling—Disabled
Damper—Disabled
Test Test Fan—Enabled
Heating—Enabled
Cooling—Enabled
Damper—Enabled
Fan only Fan only Fan—Enabled
Heating—Disabled
Cooling—Disabled
Damper—Enabled
Not present Determined by controller Fan—Enabled
Heating—Enabled
Cooling—Enabled
Damper—Enabled
Heat Any state Heating Fan—Enabled
Heating—Enabled
Cooling—Disabled
Damper—Enabled
Morning warm up Any state Pre-heat Fan—Enabled
Heating—Enabled
Cooling—Disabled
Damper—Disabled
