Trane VariTrane VSEF User Manual

VAV-SVX08R-EN
29
Table 7. Parallel fan-powered units — lb/kg
Unit Size
Single Wall
Dual Wall
VPxF
Suppres-
sor
VPCF VPEF
VPWF
VPCF VPEF
VPWF
1–Row 2–Row 1–Row 2–Row
0502SQ
81/37 110/550 92/42 95/43 115/52 144/65 126/57 129/59 15.5/7.0
0602SQ
80/36 109/49 91/41 94/43 114/52 143/65 125/57 128/58 15.5/7.0
0603SQ
83/38 112/51 105/48 108/49 117/53 146/66 139/63 142/64 16.5/7.5
0802SQ
81/37 110/50 92/42 95/43 115/52 144/65 126/57 129/59 15.5/7.0
0803SQ
83/38 112/51 105/48 108/49 117/53 146/66 139/63 142/64 16.5/7.5
0804SQ
84/38 113/51 106/48 109/49 118/54 147/67 140/64 143/65 16.5/7.5
1002SQ
82/37 111/50 93/42 96/44 116/53 145/66 127/58 130/59 15.5/7.0
1003SQ
84/38 113/51 106/48 109/49 118/54 147/67 140/64 143/65 16.5/7.5
1004SQ
85/39 114/52 107/49 110/50 119/54 148/67 141/64 144/65 16.5/7.5
1005SQ
98/44 128/58 120/54 123/56 132/60 162/73 154/70 157/71 16.5/7.5
1006SQ
114/52 144/65 127/58 130/59 148/67 178/81 161/73 164/74 20.5/9.3
1007SQ
122/55 152/69 135/61 138/63 156/71 186/84 169/77 172/78 20.5/9.3
1203SQ
85/39 114/52 107/49 110/50 119/54 148/67 141/64 144/65 16.5/7.5
1204SQ
86/39 115/52 108/49 111/50 120/54 149/68 142/64 145/66 16.5/7.5
1205SQ
99/45 129/59 121/55 124/56 133/60 163/74 155/70 158/72 15.5/7.0
1206SQ
115/52 145/66 128/58 131/59 149/68 179/81 162/73 165/75 20.5/9.3
1207SQ
123/56 153/69 136/62 139/63 157/71 187/85 170/77 173/78 20.5/9.3
1404SQ
87/39 116/53 109/49 112/51 121/55 150/68 143/65 146/66 16.5/7.5
1405SQ
100/45 130/59 122/55 125/57 134/61 164/74 156/71 159/72 16.5/7.5
1406SQ
116/53 146/66 129/59 132/60 150/68 180/82 163/74 166/75 20.5/9.3
1407SQ
124/56 154/70 137/62 140/64 158/72 188/85 171/78 174/79 20.5/9.3
1606SQ
117/53 147/67 130/59 133/60 151/68 181/82 164/74 167/76 20.5/9.3
1607SQ
125/57 155/70 138/63 141/64 159/72 189/86 172/78 175/79 20.5/9.3
Table 8. Series fan–powered units — lb/kg
Unit Size
Single Wall
Dual Wall
VSxF
Suppressor
VSCF VSEF
VSWF
VSCF VSEF
VSWF
1–Row 2–Row 1–Row 2–Row
0402SQ
78/35 104/47 85/39 87/39 93/42 119/54 100/45 102/46 11.0/5.0
0502SQ
78/35 104/47 85/39 87/39 93/42 119/54 100/45 102/46 11.0/5.0
0602SQ
77/35 103/47 84/38 86/39 92/42 118/54 99/45 101/46 11.0/5.0
0603SQ
76/34 105/48 88/40 92/42 100/45 129/59 112/51 116/53 16.5/7.5
0604SQ
87/39 116/53 99/45 103/47 111/50 140/64 123/56 127/58 16.5/7.5
0802SQ
79/36 105/48 86/39 88/40 94/43 120/54 101/46 103/47 11.0/5.0
0803SQ
77/35 106/48 89/40 93/42 101/46 130/59 113/51 117/53 16.5/7.5
0804SQ
88/40 117/53 100/45 104/47 112/51 141/64 124/56 128/58 16.5/7.5
1002SQ
81/37 107/49 88/40 90/41 96/44 122/55 103/47 105/48 11.0/5.0
1003SQ
80/36 109/49 92/42 96/44 104/47 133/60 116/53 120/54 16.5/7.5
UUnniitt IInnssttaallllaattiioonn
