11
Mounting
PINV2000 Mounting Dimensions*
9.17 in. (233 mm)
5.73 in. (145.5 mm)
0.22 in. (5.6 mm)
0.36 in. (9.1 mm)
9.65 in. (245 mm)
9.17 in. (233 mm)
0.63 in.
(16 mm)
0.63 in.
(16 mm)
*All mounting dimensions are accurate to +/- 0.1 inch (2.5 mm).
