Triumph Speed Twin User Manual

MAINTENANCE AND ADJUSTMENT
144
Bonneville T100, Scrambler 900 and
Speed Twin 900
1
2
3
1. Wire retainer
2. Headlight bulb
3. Position bulb
To remove the headlight and position
light bulb:
▼ While supporting the light unit,
disconnect the multipin electrical
connector from the headlight bulb
and the connector from the position
light.
▼ Remove the rubber dust cover.
▼ Unhook the headlight bulb's wire
retainer.
▼ The headlight bulb can now be
removed.
▼ To remove the position light bulb,
detach the bulb holder from the
headlight body and release the bulb.
▼ Installation is the reversal of
removal.
Bonneville T120 (all models),
Speed Twin 1200 and Thruxton RS
1
2
1. Wire retainer
2. Headlight bulb
To remove the headlight and position
light bulb:
▼ While supporting the light unit,
disconnect the multipin electrical
connector from the headlight bulb.
▼ Remove the rubber dust cover.
▼ Unhook the headlight bulb's wire
retainer.
▼ The headlight bulb can now be
removed.
▼ Installation is the reversal of
removal.
▼ The position bulb is situated within
the headlight assembly and is a
sealed, maintenance-free LED unit.

Triumph Speed Twin Specifications

General

Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel-twin
Transmission	6-speed
Dry Weight	196 kg (432 lb)
Fuel Capacity	14.5 liters (3.8 US gallons)
Tires (Front)	120/70 ZR17
Tires (Rear)	160/60 ZR17
Max Power	100 PS / 98.6 bhp (73.6 kW) @ 7, 250 rpm
Max Torque	112 Nm @ 4, 250 rpm
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Brembo M50 4-piston calipers, 320mm discs, ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston caliper, ABS
Seat Height	809 mm (31.8 in)
Frame	Tubular steel
