Triumph Speed Twin User Manual

GENERAL INFORMATION
62
Brake Lever Adjusters
Warning
Do not attempt to adjust the levers
with the motorcycle in motion as this
may lead to loss of motorcycle control
and an accident.
After adjusting the levers, operate the
motorcycle in an area free from traffic
to gain familiarity with the new lever
setting.
Do not loan your motorcycle to anyone
as they may change the lever setting
from the one you are familiar with
causing loss of motorcycle control and
an accident.
An adjuster is mounted to the front
brake lever. The adjuster allows the
distance from the handlebar to the
brake lever to be changed to suit the
span of the rider's hands.
Speed Twin 1200 and Thruxton RS Only
1
2
1. Brake lever
2. Adjusting screw
To adjust the brake lever:
▼ Push the brake lever forward
and turn the adjusting screw in
to increase the distance or out
to shorten the distance from the
handlebar.
All Other Models
2
1
1. Brake lever adjuster wheel
2. Arrow mark
To adjust the brake lever:
▼ Push the brake lever forward and
turn the adjuster wheel to align
one of the numbered positions with
the arrow mark on the brake lever
holder.
▼ The distance from the handlebar
grip to the released brake lever is
shortest when set to number five,
and longest when set to number
one.

Triumph Speed Twin Specifications

General

Engine Type	Liquid-cooled, 8-valve, SOHC, 270° crank angle parallel-twin
Transmission	6-speed
Dry Weight	196 kg (432 lb)
Fuel Capacity	14.5 liters (3.8 US gallons)
Tires (Front)	120/70 ZR17
Tires (Rear)	160/60 ZR17
Max Power	100 PS / 98.6 bhp (73.6 kW) @ 7, 250 rpm
Max Torque	112 Nm @ 4, 250 rpm
Rear Suspension	Twin shocks, adjustable preload
Front Brakes	Brembo M50 4-piston calipers, 320mm discs, ABS
Rear Brakes	Single 220mm disc, Nissin 2-piston caliper, ABS
Seat Height	809 mm (31.8 in)
Frame	Tubular steel
