Triumph Tiger User Manual

Maintenance and Adjustment
64
*Evaporative system fitted to California models only.
Brake pads - check wear levels Day
•••• •
Brake master cylinders - check for fluid leaks -
•••• •
Brake calipers - check for fluid leaks and seized pistons -
•••• •
Rear suspension linkage - check/lubricate -
••
Drive chain - lubricate Every 200 miles (300 kms)
Drive chain - wear check Every 500 miles (800 kms)
Drive chain slack - check/adjust Day
•••• •
Drive chain rubbing strip - check -
••• •
Fasteners - inspect visually for security Day
•••• •
Wheels - inspect for damage Day
•••• •
Wheel bearings - check for wear/smooth operation -
•••• •
Tyre wear/tyre damage - check Day
•••• •
Tyre pressures - check/adjust Day
•••• •
Clutch cable - check/adjust Day
•••• •
Secondary air injection system - check/clean -
••
Stand - check operation Day
•••• •
Secondary exhaust pipe clamp bolts - check/adjust -
•••• •
Fuel and evaporative loss* hoses - renew -
•
Operation Description Odometer Reading in Miles (Kms) or Time Period, whichever comes first
First
Service
A Service B Service C Service D Service
Every 500
(800)
1 month
6,000
(10,000)
1 year
12 , 0 0 0
(20,000)
2 years
18 , 0 0 0
(30,000)
3 years
24,000
(40,000)
4 years

Triumph Tiger Specifications

General

Displacement	888 cc
Compression Ratio	11.27:1
Fuel System	Multipoint sequential electronic fuel injection
Exhaust	Stainless steel 3 into 1 header system, side mounted stainless steel silencer
Gearbox	6-speed
Swingarm	Twin-sided, cast aluminium
Front Wheel	Cast aluminium, 19 x 2.5 in
Rear Wheel	Cast aluminium, 17 x 4.25 in
Front Tyre	100/90-19
Rear Tyre	150/70R17
Wet Weight	210 kg
Engine	Liquid-cooled, in-line 3-cylinder
Bore x Stroke	78.0 mm x 61.9 mm
Clutch	Wet, multi-plate
Frame	Tubular steel frame
Rear Brakes	Single 255 mm disc, ABS
Tank Capacity	20 L
Wheelbase	1, 555 mm
