99
Maintenance and Adjustment
Position Lamp Bulb Replacement
1. Position lamp bulb (left hand)
2. Position lamp bulb (right hand)
The position lamps are fitted to the left and
right of each headlight. To replace a bulb,
remove the cockpit infill panel for the bulb to
be replaced, detach the rubber retainer from
the headlight and pull out the bulb.
Installation is the reverse of the removal
procedure.
Rear Light
Rear Light Replacement
The rear light unit is a sealed, maintenance
free LED unit.
Direction Indicator Lights
Bulb Replacement
1. I n d i c a t o r l e n s
2. Securing screw
The lens on each indicator light is held in
place by a securing screw located in the body
of the light.
Release the screw and remove the lens to
gain access to the bulb for replacement.
1
2
ccoa
1
2
