Assembly & Set-Up
3
7
NOTE: 
models. The tiller depicted may differ from yours.
WARNING! To prevent personal injury or property
damage, do not start the engine until all assembly
steps are complete and you have read and
understand the safety and operating instructions in
this manual.
Recommended Tools for Assembly
 Two ⁄” open-end wrenches
 Block of wood (to support tiller when removing wheels)
 Tire pressure gauge
 Clean oil funnel
 
specifications and quantity required.
Assembly
Unpacking Instructions
NOTE: While unpacking, do not severely bend any of the control
cables.
 The tiller is heavy, do not attempt to remove it from
the shipping platform until instructed to do so in these
Assembly steps.
2. Remove any packaging material from the carton. Remove
any staples from the bottom of the carton and remove the
carton from the shipping platform.
3. Remove all loose parts from the carton. Check that you
have the items listed in the Contents of Carton list (contact
your local dealer or the factory if items are missing or
damaged).
Handle
NOTE: All references to the right or left side of the tiller are from

 Remove two hex screws (⁄
nuts (⁄⁄
⁄

Lower
Handlebar
Support Brackets
Hex Screw
Hex Screw
Flange
Lock
Nuts
Carriage Bolt
Knob
Bell Washer
Figure 3-1
