Unhook the idler spring from the hex bolt on the auger
Lift the auger belt from the auger pulley, and slip belt 7.
between the support bracket and the auger pulley. See
Fig. 7-5.
Replace auger drive belt by following instructions in 8.
reverse order.
Drive Belt
as follows:
To prevent spillage, remove all fuel from tank by running
engine until it stops. Do not attempt to pour fuel from the
engine.
Remove the plastic belt cover on the front of the engine by 2.
Carefully pivot the snow thrower up and forward so that it 3.
rests on the auger housing.
Remove the frame cover from the underside of the snow
thrower by removing self-tapping screws which secure it.
Ref. Fig. 7-2.
To remove the belt from the pulleys proceed as follows:5.
Roll the auger belt off the engine pulley.a.
b.
Lift the drive belt off engine pulley.c.
Back out the stop bolt until the support bracket rests on
Bracket
se c t i O n 7 — se r v i c e
