3
GEN-45X GEN-55X
15343 15344
7.3 Hp
4 stroke motor
338 cc 389 cc
Gasoline
120 V / 240 V / 60 Hz
Gas Power Generator
Two 120 V double polarized contacts, one 240 V two- phase contacts
7.3 gal
10 Hp
6 Hp
8.7 Hp
97 dB at 13 ft
Continuous work at nominal power 30 min rest per tank spent
13 Hp11 Hp
Fuel Requirements
• The generator is built with an air-cooled, 4 – stroke motor using unleaded pure gasoline.
• For no reason at all mix oil with the fuel.
• For no reason at all use fuel mixed with ethyl alcohol (gasohol), ethanol, or methane. These attract
humidity causing separation and acid build-up while stored. Acidity may damage the motor fuel system when stored.
• To prevent issues with the motor, empty the fuel system before storing the generator during 30 days or longer
periods of time. Empty the gasoline tank, start the motor and leave it running until the fuel and carburetor lines are
empty. The next season, use fresh gasoline.
• Never pour into the gasoline tank, motor or carburetor cleaning liquids because it can result in permanent damage.
WARNING
Technical Data
ENGLISH
Code
Description
Rated Motor Power
Motor
Cylinder Capacity
Fuel
Fuel Tank
Voltage
Maximum Power at Startup
Output
Maximum Operation Power
Noise Level
Work Cycle
