TSC DA200 Series User Manual

- 5 -
1.3 General Specifications
General Specifications
Physical
dimensions
195 mm x 172 mm x 165 mm
Note : 195 mm x 178.5 mm x 165 mm (incl. open lever)
Mechanism
Plastic with double-walled clamshell design
Weight
1.5 kg
Power
External universal switching power supply
Input: AC 100-240V, 50-60Hz
Output: DC 24V, 2.5A, 60W
Environmental
condition
Operation: 5 ~ 40˚C, 25~85% non-condensing
Note : Peeler mode & Linerless mode : 40˚C/ 45%
Storage: -40 ~ 60 ˚C, 10~90% non-condensing
Environmental
concern
Comply with RoHS, WEEE
1.4 Print Specifications
Print Specifications
203 dpi models
300 dpi models
Print head resolution
(dots per inch/mm)
203 dots/inch
(8 dots/mm)
300 dots/inch
(12 dots/mm)
Printing method
Direct thermal
Dot size
(width x length)
0.125 x 0.125 mm
(1 mm = 8 dots)
0.084 x 0.084 mm
(1 mm = 11.8 dots)
Max. print speed
(inches per second)
127 mm (5”)
102 mm (4”)
2,3 ips for peeler mode
Max. print width
108 mm
105.7 mm
Max. print length
90” (2286 mm)
Printout bias
Vertical: max. 1 mm
Horizontal: max. 1 mm
1.5 Media Specifications
Media Specifications
Media roll capacity
127 mm (5“) OD
Media core diameter
1” (1.5”) ID core
Note : 1.5’’ adapter
Media type
Continuous, die-cut, black mark, External fan-fold, receipt,
Linerless label (w/ linerless kit)
Media wound type
Outside wound
Media width
19 mm ~ 114 mm (0.7”~ 4.5”)
