8
5. Media Side Assemblies-2
NO.
PART NO.
DESCRIPTION
SUGGEST
ATTACH RATE
13*
--
E-RING ID10*OD20*T1.0
14*
--
MACHINE SCREW, M6*12
15*
--
MACHINE WASHER SCREW,
M4*10
16*
--
MACHINE SCREW, M4*15
17*
--
MACHINE SCREW, M3*6
18*
--
MACHINE SPRING WASHER
SCREW, M4*10
19*
--
MACHINE SCREW, M3*8
20*
--
MACHINE SCREW, M4*8
* NOTE: Available only in Hardware Field Kit (P/N: SP-MH241-0052)
