TSC PRINTRONIX AUTO ID TC200 Series User Manual

32
5.5 Printer Function
Printer Function could be found in Printer Configuration. “Printer Function” will be shown on the left side of the window.
Functions
Description
Calibrate Sensor
Detect media types and the size of the label
RTC Setup
Synchronize printer with Real Time Clock on PC
Factory Default
Initialize the printer to default settings
Reset Printer
Reboot printer
Print Test Page
Print test page according to the specified label size and sensor type.
Configuration Page
Print printer configurations
Dump Text
Activate the printer to dump mode
Ignore AUTO.BAS
Ignore AUTO.BAS file when printer boot up.
Exit Line Mode
Exit the line mode to page mode
Enter Line Mode
Leave page mode and enter line mode
Reset WiFi
Restore the WiFi settings to defaults.

TSC PRINTRONIX AUTO ID TC200 Series Specifications

General

Print Technology	Thermal Transfer / Direct Thermal
Resolution	203 dpi (8 dots/mm)
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-4°F to 140°F (-20°C to 60°C)
Print Speed	6 IPS (152 mm/s)
Max Print Width	4.09" (104 mm)
Connectivity	USB 2.0, RS-232
Media Handling	fan-fold, continuous
Media Type	Roll-fed or fan-fold
Media Width	1.0 to 4.64 inches
Media Core Diameter	1 inch (25.4 mm) or 1.5 inches (38.1 mm)
Media Max Roll Diameter	5 inches (127 mm)
Ribbon Width	1.57 inches (40 mm) to 4.33 inches (110 mm)
Ribbon Core Diameter	0.5 inches
Ribbon Length	984 feet (300 meters)
Power	100-240V AC, 50-60 Hz
Supported Barcode Types	Data Matrix, QR Code
