TSC Printronix MB240 Series User Manual

27
4 Knob Adjustment
Printhead Pressure Adjustment Knob has 6 levels’ adjustment for 1” to 2” and 3” to 4” width media.
Different number means different pressure to the media . Due to printer’s paper alignment is on left side of the mechanism, different
media width requires the different pressure. Users can try which level can meet their expectation.
Printhead Pressure Adjustment
range from 3” to 4" media width
Print Head Pressure Adjustment range
from 1~2" media width
◼
0 means regular media thickness
(0.14-0.16mm) pressure setting.
◼ -1 means lower pressure for thin
paper media
◼ +1 means higher pressure for
thick media

TSC Printronix MB240 Series Specifications

General

Type	Industrial Barcode Printer
Resolution	203 dpi (8 dots/mm)
Media Type	Direct Thermal, Thermal Transfer
Communication Interface	USB, Serial, Ethernet
Interface	USB 2.0, RS-232, Parallel, Ethernet 10/100
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-8, EAN-13, Interleaved 2 of 5, Codabar, PDF417, QR Code, Data Matrix
Scanning Method	Thermal Transfer/Direct Thermal
Operating Temperature	41°F to 104°F (5°C to 40°C)
Storage Temperature	-40°F to 140°F (-40°C to 60°C)
