TSC TTP-2410MT Series User Manual

- 7 -
2. Operations Overview
2.1 Unpacking and Inspection
This printer has been specially packaged to withstand damage during shipping. Please
carefully inspect the packaging and printer upon receiving the bar code printer. Please
retain the packaging materials in case you need to reship the printer. Unpacking the
printer, the following items are included in the carton.
If any parts are missing, please contact the Customer Service Department of your
purchased reseller or distributor.
 One printer unit
 One Windows labeling software/Windows driver CD disk
 One quick installation guide
 One power cord
 One USB interface cable

TSC TTP-2410MT Series Specifications

General

Model	TTP-2410MT Series
Resolution	203 dpi
Ribbon core diameter	25.4 mm (1 inch)
Ribbon length	300 m
Processor	32-bit RISC
Interface	USB, Serial, Parallel, Ethernet
Type	Barcode Printer
Max. print width	104 mm
Memory	8 MB Flash
Media type	Continuous, die-cut, black mark
Media width	25.4 mm - 114 mm
Media core diameter	25.4 mm (1 inch)
Ribbon width	110 mm
Power	100-240V AC, 50/60 Hz
Supported Barcodes	Code 39, Code 128, UPC-A, UPC-E, EAN-13, EAN-8, Interleaved 2 of 5, Codabar, PDF417, Data Matrix, QR Code
Operating Temperature	5°C to 40°C
Storage Temperature	-40°C to 60°C
Certifications	CE, FCC
