TSC AUTO ID Technology Co., Ltd. 53 Copyright 2009 All Rights Reserved.
AZTEC
Description
This command is used to define the AZTEC 2D bar code. Supported by V6.60EZ.
Syntax
AZTEC x,y,rotate,[size,]ecp,]flg,]menu,]multi,]rev,]"content"
Parameter Description
x Horizontal start position (in dots)
y Vertical start position (in dots)
rotate Rotation
0: No rotation
90: 90 degrees
180: 180 degrees
270: 270 degrees
size Element module size (1 to 20), default is 6
ecp Error control (& symbol size/type) parameter
0 : default error correction level
1 to 99 : minimum error correction percentage
101 to 104 : 1 to 4-layer Compact symbol
201 to 232 : 1 to 32-layer Full-Range symbol
300 : a simple Aztec "Rune"
flg 0 : input message is straight bytes
1 : input uses "<Esc>n" for FLG(n), "<Esc><Esc>" for "<Esc>"
menu Menu symbol (0 : no, 1 : yes), default is 0
multi Number of symbols (1 to 26), default is 6
rev Output to be reversed (0 : no, 1 : yes), default is 0
content Barcode content
Example
SIZE 3,3
GAP 0,0
SPEED 4
DENSITY 8
DIRECTION 0
REFERENCE 0,0
OFFSET 0.00
SET CUTTER OFF
SET TEAR ON
CLS
AZTEC 200,10,0,"ABCDEFGHIJKLMNOPQRSTUVWXYZ0123456789"
PRINT 1
CLS
