• If the tractor must be lifted for servicing, take it to a suitably equipped workshop.
• Carry out the following operations before any operation about the tractor. Engage the four-wheel drive, the first gear and the
parking brake and put chocks to the wheels touching the ground.
• Before lifting the tractor, avoid its swinging by means of wooden wedges applied to the front axle
• Use jack lifts of suitable capacity and apply them at the center of the front and rear axles and paying due attention to weight
distribution.
• No decals for the lifting point are applied on the tractor, as they would be, too difficult to apply in the available spaces and
would be all too easily removed or effaced during normal operation of the tractor.
- NOTE
Apply the jack lift to the lifting points according to the type of operation and following the safety procedures given before.
FRONT AXLE
REAR AXLE
8. HOW TO USE OF JACK
MAINTENANCE AND SERVICE
5-24
