Components
Your power scooter comes partially disassembled for protection during
shipment. After unpacking, please familiarize yourself with the following
components (See Figs. 1 and 2)
6. Foldable armrests 1. Control Panel
7. Rear basket and support tube 2. Front Column
8. Battery packs (detachable) 3. Front Wheel
9. Rear wheels 4. Foot Platform
10. Anti tip wheels 5. Seat Shell
11. Battery Charger
Figure 2 Figure 1
