Tzora Titan User Manual

Assembly Instructions
It is very easy to assemble your scooter. Please follow the steps below.
Contact your service center if any problems occur.
Chassis Installation
1. Insert both batteries into the back chassis. (See Fig. 7).
2. Using the handle located behind the seat, raise the front chassis and
connect it to the back chassis. Make sure they are aligned and locked
(See Fig. 4).
Figure 4
Tiller Positioning
1. Pull up the tiller handle, in order to release the position lock (See Fig 5).
2. Adjust the tiller to a driving position, according to your own preference.
Figure 5

Tzora Titan Specifications

General

Brand	Tzora
Model	Titan
Category	Scooter
Language	English
