UNI-T UT207 User Manual

Non sine wave must follow the below data to adjust:
Peak factor: 1.4~2.0, add 1.0% on the stated accuracy.
Peak factor: 2.0~2.5, add 2.5% on the stated accuracy
Peak factor: 2.5~3.0, add 4.0% on the stated accuracy.
J. Temperature (UT208 only)
Range
40
~1000
-40 ~1832
Resolution
1
1
Overload protection
250VAC
Accuracy
-40 ~0 : (3%+4)
0 ~400 : (1%+3)
400 ~1000 :
(2%+10)
-40
~32 : (3%+8)
32
~752 : (1%+6)
752
~1832 :
(2%+18)
Model UT207/208: OPERATING MANUAL
48

UNI-T UT207 Specifications

General

Backlight	Yes
AC current range	66 - 1000 A
DC voltage range	6.6 - 600 V
Resistance range	20 - 20000 Ω
Basic accuracy (frequency)	±(0.1%+3)
Basic accuracy (DC current)	±(1.5%+8)
Basic accuracy (DC voltage)	±(0.8%+1)
Basic accuracy (resistance)	±(1%+2)
Temperature measurement range	-40 - 1000 °C
Dimensions (WxDxH)	105 x 45 x 286 mm
Battery voltage	9 V

Weight and Dimensions

Weight	533 g
