UNI-T UT3216 User Manual

UT3200 Series User Manual
6
1.2 Specifications and functions
Specifications
Functions
Display
Numerical reading
Curve figure
Histogram figure
Test
Thermocouple input: J, K, T, E, S, N, B, R
Testing range: -200.0℃-1800.0℃ (different model)
Resolution ratio: 0.1℃
Number of channel: 8-32 (different model)
Speed: fast, slow
Major functions
Sorting: each channel can set upper and lower limits
Beep: high/low temperature
Correction: amend each channel values independently
Lock button
Print Screen
Storage
FAT(File Allocation Table): allow to create format .csv
document, every channel data can save into USB (Hard
drives are not supported)
Interface & Protocol
RS232 communication interface
USB communication interface
Compatible with SCPI instruction set
Remote control
Support up to 115200bps baud rate, compatible with
SCPI protocol, ASCIl transport
System config
Chinese, English switch
Date, time, button sound
Administrator / User account, Administrator can set the
password
Environmental temperature
Indicator: temperature 15℃-35℃ humidity < 80%RH
Operation: temperature 10℃-40℃ humidity 10-90%RH
Storage: temperature 0℃-50℃ humidity 10-90%RH
Size
L340mm×W214mm×H89mm
Weight
3.5kg（net weight）
1.3 Instrument accuracy
Instrument accuracy does not include standard contact compensation accuracy. Standard
contact compensation adds ± 0.5 °C to the thermocouple accuracy of measuring temperature.
The measurement accuracy of thermocouple sensors should be based on the sensor
manufacturer's standard.
