UNI-T UT33B User Manual

Accuracy Specifications(3)
C. DC Current
Remark:
l At 10A Range: For continuous measurement 10 seconds and interval not less
than 15 minutes.
Range Resolution
200µA
2000µA
20mA
200mA
10A
Accuracy
UT33B UT33C UT33D
Overload
Protection
(1.2%+2)
(2%+5)
0.1µA
1µA
10µA
100µA
10mA
315mA, 250V
fast type fuse:
φ 5x20mm
Un-Fused
(1%+2)
(1%+2)
33
Model UT33B/C/D: OPERATING MANUAL

UNI-T UT33B Specifications

General

Product type	Digital multimeter
AC voltage range	200 - 500 V
DC current range	0.2 - 10 A
DC voltage range	0.2 - 500 V
Basic accuracy (DC current)	±(1%+2)
Basic accuracy (DC voltage)	±(0.5%+2)
Basic accuracy (resistance)	±(0.8%+2)
Dimensions (WxDxH)	73.5 x 35 x 130 mm
Battery voltage	9 V
Battery low indication	Yes

Weight and Dimensions

Weight	156 g
