Model UT513: OPERATING MANUAL
Press COMP button to select compare feature.
COMP symbol displays on the LCD..
Press and buttons to set the compare value
Below is the list in sequence of the compare value:
10M , 20M , 30M , 40M , 50M , 60M , 70M ,
80M , 90M ,100M , 200M , 300M , 400M ,
500M , 600M , 700M , 800M , 900M ,1G ,
2G , 3G , 4G , 5G , 6G , 7G , 8G , 9G ,
10G ,20G , 330G , 40G , 50G , 60G , 70G ,
80G , 90G , 100G ,200G , 300G , 400G ,
500G , 600G , 700G , 800G , 900G
Press and hold TEST button for 2 seconds to carry
out the measurement.
The NG symbol will display if the insulation
resistance value is smaller than resistance value.
Otherwise GOOD symbol will be displayed.
