Specification
Unitech MS350
Specification Model MS350
Operational
Light Source 630 nm Visible Red LED
Optical System 2048 pixel CCD
(Charge-coupled device)
Depth of Scan Field
0~270mm (CODE 39, PSC=90%,
20mil)
0~180mm for 13mil
0~60mm for 5mil
5mm~50mm for 4mil
Scan Speed 300 scans/sec
Resolution
0.1mm (4mil) Code39, PCS=90%
Print Contrast 30% or more
Scanning Angle Front: 60° Rear: 60° Yaw: 70°
Decode Capability Auto-discriminates all standard
barcodes and some 2D symbologies
including PDF-417 and RSS code;
Other symbologies can be ordered
optionally
Beeper Operation 7 tones or no beep
Indicator on imager
