Unitech MS910 User Manual

43
Unitech electronics co., ltd.
5F., No.135, Ln. 235, Baoqiao Rd., Xindian Dist., New Taipei City 231, Taiwan (R.O.C.)
 Tel: + 886 2 89121122  Fax: +886 2 89121810  website: www.ute.com
Appendix B
Examples of Connection
to Android and iOS Smart
p
hones
BluetoothConnect needs to be installed only when you have NO wireless input application on
your Android device. Android 2.x devices can work with MS910 in the SPP mode ONLY. The
SPP mode or/and the HID mode are not definitely compatible with each version of Android OS,
and thus depends on the Android-based hardware specifications defined by the Android device
manufacturers.
Smartphone Connection (Android)
1. Before connection between the scanner and your mobile device, pair with the scanner via
[SPP]; see the topic: Connecting via Serial Port Profile (SPP) Mode.
2. Install BluetoothConnect.apk (available on CD) onto your mobile device and enter the
program.
Note: Before installation, enable ‘Unknown Sources” in Android Authority.
3. Once you enter the BluetoothConnect, the application may ask you to enable Bluetooth
connection, and then click [Yes].

Unitech MS910 Specifications

General

Type	Handheld bar code reader
Wavelength	625 nm
Sensor type	CCD / CMOS
Scanner type	1D/2D
Read rate (max)	240 reads/s
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 32, Code 39, Code 93, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), MSI, Plessey, Telepen, U.P.C.
2D (matrix & stacked) barcodes supported	Compact Matrix Code, Data Matrix
Wireless range	10 m
Standard interfaces	Bluetooth
Connectivity technology	Wireless
Certification	CE, FCC ClassB
Product color	Black, Blue
LED indicators	Yes
Housing material	Acrylonitrile butadiene styrene (ABS)
Cables included	USB
Battery voltage	3.7 V
Power consumption	150 mA
Power source type	Battery
Number of reads per charge	5000
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 85 %

Weight and Dimensions

Depth	65 mm
Width	24 mm
Height	18 mm
Weight	24.6 g
