EAGLE ONE PRIMA | LIBRETTO ISTRUZIONI - USER HANDBOOK - MANUEL D’INSTRUCTIONS | 109
12.3
SCHÉMA CHAUDIÈRE
DONNÉES PROJET DIRECTIVE PED 97/23/CE
VOLUMES 1,5 l
TS 139°C
P.V.S. 2.5 Bar
PT 4 Bar
FLUIDE H2O
ÉLÉMENT Q.TÉ
NUMÉRO PARTIE
DESCRIPTION MATÉRIAU
1 1 98031201 Bride inférieure
2 1 98031201 Corps de chaudière INOX AISI 316L
3 1 98031201 Bride supérieure INOX AISI 316L
4 2 00080750 Vis prisonnier M6x25 INOX
5 1 00080800 Vis prisonnier M3x8 INOX
6 3 00081410 Vis prisonnier M6x20 INOX
5
3
2
1
4
1
6
4
4
4
3
2
6
6
